Quick Search by Pitch
0.8mm Vertical (Through hole) pin header
Gender: Male
Pitch: 0.8mm pitch
Row: Single
Circuits: 2 - 40 pins
Version: Straight (Dip) Through hole
Insulator height: 1.50mm or customizable
Pin lengths: customizable
1.0mm Vertical (Through hole) pin header
Gender: Male
Pitch: 1.0mm (.039″) inch pitch
Row: Dual Row
Circuits: 2 - 80 pins
Version: Straight (Dip) Through hole
Insulator height: 1.50mm or customizable
Pin lengths: customizable
1.0mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 1.0mm (.039″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Right-angle (Dip) Through hole
Insulator height: 1.0mm or customizable
Pin lengths: customizable
1.0mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 1.0mm (.039″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Dip) Through hole
Insulator height: 1.0mm or customizable
Pin lengths: customizable
1.0mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 1.0mm (.039″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: SMT (Surface Mount)
Insulator height: 1.0mm or customizable
Pin lengths: customizable
1.0mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 1.0mm (.039″) inch pitch
Row: Single
Circuits: 2 - 80 pins
Version: SMT (Surface Mount)
Insulator height: 1.0mm or customizable
Pin lengths: customizable
1.27mm Vertical (Through hole) pin header
Gender: Male
Pitch: 1.27mm (.050″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Straight (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm Vertical (Through hole) pin header
Gender: Male
Pitch: 1.27mm (.050″) inch pitch
Row: Single
Circuits: 2 - 80 pins
Version: Straight (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 1.27mm (.050″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Right-angle (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 1.27mm (.050″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Through hole)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 1.27mm (.050″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: SMT (Surface Mount)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 1.27mm (.050″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: SMT (Surface Mount)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.0mm Vertical (Through hole) pin header
Gender: Male
Pitch: 2.0mm (.079″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Vertical (Through hole)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.0mm Vertical (Through hole) pin header
Gender: Male
Pitch: 2.0mm (.079″) inch pitch
Row: Single
Circuits: 2 - 80 pins
Version: Vertical (Through hole)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.0mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 2.0mm (.079″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Right-angle (Through hole)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.0mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 2.0mm (.079″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Through hole)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.0mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 2.0mm (.079″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: SMT (Surface Mount)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.0mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 2.0mm (.079″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: SMT (Surface Mount)
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.54mm Vertical (Through hole) pin header
Gender: Male
Pitch: 2.54mm (.100″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Vertical (Through hole)
Insulator height: 2.50mm or customizable
Pin lengths: customizable
2.54mm Vertical (Through hole) pin header
Gender: Male
Pitch: 2.54mm (.100″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Vertical (Through hole)
Insulator height: 2.50mm or customizable
Pin lengths: customizable
2.54mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 2.54mm (.100″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Right-angle (Through hole)
Insulator height: 2.50mm or customizable
Pin lengths: customizable
2.54mm Right-angle (Through hole) pin header
Gender: Male
Pitch: 2.54mm (.100″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Through hole)
Insulator height: 2.50mm or customizable
Pin lengths: customizable
2.54mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 2.54mm (.100″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version:SMT (Surface Mount)
Insulator height: 2.50mm or customizable
Pin lengths: customizable
2.54mm SMT (Surface Mount) pin header
Gender: Male
Pitch: 2.54mm (.100″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version:SMT (Surface Mount)
Insulator height: 2.50mm or customizable
Pin lengths: customizable
Female Header Connectors
Quick Search by Pitch
1.0mm Vertical (Through hole) Female header
Gender: Female
Pitch: 1.0mm (.039″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Vertical (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.0mm Vertical (Through hole) Female header
Gender: Female
Pitch: 1.0mm (.039″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Vertical (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.0mm Right-angle Female header
Gender: Female
Pitch: 1.0mm (.039″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Right-angle (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.0mm Right-angle Female header
Gender: Female
Pitch: 1.0mm (.039″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.0mm SMT (Surface-Mount) Female header
Gender: Female
Pitch: 1.0mm (.039″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Surface-Mount
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.0mm SMT (Surface-Mount) Female header
Gender: Female
Pitch: 1.0mm (.039″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Surface-Mount
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm Vertical (Through hole) Female header
Gender: Female
Pitch: 1.27mm (.050″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Vertical (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm Vertical (Through hole) Female header
Gender: Female
Pitch: 1.27mm (.050″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Vertical (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm Right-angle Female header
Gender: Female
Pitch: 1.27mm (.050″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Right-angle (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm Right-angle Female header
Gender: Female
Pitch: 1.27mm (.050″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Dip) Through hole
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm SMT (Surface Mount) Female header
Gender: Female
Pitch: 1.27mm (.050″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Surface Mount
Insulator height: 2.0mm or customizable
Pin lengths: customizable
1.27mm SMT (Surface Mount) Female header
Gender: Female
Pitch: 1.27mm (.050″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Surface Mount
Insulator height: 2.0mm or customizable
Pin lengths: customizable
2.0mm Vertical (Through hole) Female header
Gender: Female
Pitch: 2.0mm (.079″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Vertical (Dip) Through hole
Insulator height: 4.3mm or customizable
Pin lengths: customizable
2.0mm Vertical (Through hole) Female header
Gender: Female
Pitch: 2.0mm (.079″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Vertical (Dip) Through hole
Insulator height: 4.3mm or customizable
Pin lengths: customizable
2.0mm Right-angle Female header
Gender: Female
Pitch: 2.0mm (.079″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Right-angle (Dip) Through hole
Insulator height: 4.3mm or customizable
Pin lengths: customizable
2.0mm Right-angle Female header
Gender: Female
Pitch: 2.0mm (.079″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Dip) Through hole
Insulator height: 4.3mm or customizable
Pin lengths: customizable
2.0mm SMT(Surface-Mount) Female header
Gender: Female
Pitch: 2.0mm (.079″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Surface-Mount
Insulator height: 4.3mm or customizable
Pin lengths: customizable
2.0mm SMT(Surface-Mount) Female header
Gender: Female
Pitch: 2.0mm (.079″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Surface-Mount
Insulator height: 4.3mm or customizable
Pin lengths: customizable
2.54mm Vertical (Through hole) Female header
Gender: Female
Pitch: 2.54mm (.100″) inch pitch
Row: Single
Circuits: 2 - 40 pins
Version: Vertical (Dip) Through hole
Insulator height: 8.5mm or customizable
Pin lengths: customizable
2.54mm Vertical (Through hole) Female header
Gender: Female
Pitch: 2.54mm (.100″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Vertical (Dip) Through hole
Insulator height: 8.5mm or customizable
Pin lengths: customizable
2.54mm Right-angle Female header
Gender: Female
Pitch: 2.54mm (.100″) inch pitch
Row: single
Circuits: 2 - 40 pins
Version: Right-angle (Dip) Through hole
Insulator height: 8.5mm or customizable
Pin lengths: customizable
2.54mm Right-angle Female header
Gender: Female
Pitch: 2.54mm (.100″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Right-angle (Dip) Through hole
Insulator height: 8.5mm or customizable
Pin lengths: customizable
2.54mm SMT (Surface-Mount) Female header
Gender: Female
Pitch: 2.54mm (.100″) inch pitch
Row: single
Circuits: 2 - 40 pins
Version: Surface-Mount
Insulator height: 8.5mm or customizable
Pin lengths: customizable
2.54mm SMT (Surface-Mount) Female header
Gender: Female
Pitch: 2.54mm (.100″) inch pitch
Row: Dual
Circuits: 2 - 80 pins
Version: Surface-Mount
Insulator height: 8.5mm or customizable
Pin lengths: customizable
Female header always called as “Header connector”, Smolex provide widely range of header connector, from 2.54mm (.100″ inch) pitch to 1.0mm (.039″ inch) pitch. The number of pins (contacts) is from 2 to 40 pins per orw. There are three type: Straight (Dip Vertical), Right angle, SMT (surface mount).
If you can not find the items you interest from above items, welcome to contact us, and you will always get fully responsive from us.
